Xerox® WorkCentre® 5890 Family
PL 11.78
Parts Lists
PL 11.78 LVF BM Booklet Stapler
A
ssembly
Item Part Description
1
029K04812 BM stapler assembly (REP 11.38-
150)
2 130E10360 Staple unit home sensor (Q11-438)/
Staple unit away sensor (Q11-
439)(REP 11.48-150)
3 127E17680 BM staple unit move motor
(MOT11-435)
4 – BM stapler frame (P/O PL 11.78
Item 1)
5 077E00081 BM staple head assembly (REP
11.48-150)
6 029K04800 BM staple cartridge assembly (REP
11.37-150)
7 – Bracket (P/O PL 11.78 Item 6)
8 029K04820 BM staple cartridge
9 107E35740 Staple cartridge LED (REP 11.39-
150)
10 822E18810 LVF BM Back stop cover
