Control Panel Menus
WorkCentre 6505 Color Laser Multifunction Printer
User Guide
150
PCL Settings
Use this menu to configure settings for PCL.
Item Description
Paper Tray Specifies the paper tray used.
Paper Size Specifies the default paper size.
Orientation Specifies the paper printing direction: Portrait or Landscape. The default setting is Portrait.
2-Sided Specifies 2-sided printing options:
• 2-Sided Print: On or Off. The default setting is On when the duplex unit is installed.
• Binding Edge: Flip Long Edge or Flip Short Edge
Font Specifies the default font. The default setting is Courier.
Symbol Set Specifies the font used for symbols. The default setting is ROMAN-8.
Font Size Specifies the default font size, from 4 through 50, in increments of 0.25. Available only for
typographic fonts.
Font Pitch Specifies the character spacing. You can specify a value from 6.00 through 24.00 in
increments of 0.01. The default setting is 10.00.
Form Line Specifies the form line (the number of lines per form). You can specify a value from 5 through
128 in increments of 1. The default setting is 64.
Quantity Specifies the copies to print. You can specify a value from 1 through 999. The default setting
is 1.
Enhance
Specifies whether to perform image enhancement.
Image enhancement is a feature that makes the boundary line between black and white
smoother, to decrease jags and enhance the appearance. The default setting is On.
Hex Dump Specifies whether to print the data sent from a computer in the ASCII code corresponding to
the hexadecimal notation format to check the data contents. The default setting is Disable.
Draft Mode Specifies whether to print in draft mode. The default setting is Disable.
Line
Termination
Specifies line termination.
• Off: Line termination commands are not added.
• Add-LF: The Line Feed command is added.
• Add-CR: The Carriage Return command is added.
• CR-XX: The Line Feed and Carriage Return commands are both added.
Default Color Specifies the default color mode: Black or Color. The default setting is Black.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
