Troubleshooting
WorkCentre 6505 Color Laser Multifunction Printer
User Guide
184
Control Panel Messages
This section includes:
• Supply Status Messages on page 184
• Error Messages on page 185
The printer uses control panel messages to indicate printer status, errors, and to provide instructions.
Supply Status Messages
Status messages tell you about the status of the printer and its supplies.
Note: Xxx indicates one of the following: the Yellow Toner (Y), Cyan Toner (C), Magenta Toner (M),
Black Toner (K), a tray, or fuser. NNN indicates a numeric value.
Code/Message Condition/Reason/Solution
Replace Fuser
010-351
Time to replace the fuser.
Replace the old fuser with a new one and then restart the printer.
Insert Fuser
010-317
The fuser is not installed or it is incorrectly installed.
Install the fuser and then restart the printer.
Replace Imaging Unit It is time to replace the imaging unit.
Replace the imaging unit. For details, see the Imaging Unit instruction
sheet that came in the documentation packet with your printer.
Insert Imaging Unit The imaging unit is not installed.
Install the imaging unit. For details, see the Imaging Unit instruction sheet
that came in the documentation packet with your printer.
Insert Xxx Cartridge The Xxx toner cartridge is not installed correctly or is not installed. Install
the toner cartridge.
Replace Xxx Cartridge The toner cartridge is empty.
Replace the old toner cartridge with a new one.
Invalid Xxx The wrong toner cartridge is installed or the toner cartridge is not seated
correctly. Reseat the toner cartridge or replace the cartridge with one that
meets specifications for your printer. The region of your printer is listed on
the Configuration Page in the General section. For details on printing the
Configuration Page, see Configuration Page on page 24.
Non-Xerox
®
Toner The printer is in the custom toner mode. This message means a non-
Xerox
®
toner is installed. You could experience a decrease is print quality as
a result.
Low Density
Xxx Cartridge
Toner is not distributed evenly in the specified cartridge. Remove and shake
the cartridge, then reinstall it.

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
