Chapter3: Board Component Descriptions
X-Ref Target - Figure 3-11
Figure3‐11: GTY Bank Assignments
BANK 224
MGT_224_0
MGT_224_1
MGT_224_2
MGT_224_3
MGT_224_REFCLK_0
MGT_224_REFCLK_1
PCIE_7
Not connected
PCIE_6
PCIE_4
PCIE_5
Not connected
BANK 226
MGT_226_0
MGT_226_1
MGT_226_2
MGT_226_3
MGT_226_REFCLK_0
MGT_226_REFCLK_1
SPF0
USER_MGT_SI570_CLOCK
SPF1
SPF3
SPF2
SFP_SI5328_OUT
BANK 225
MGT_225_0
MGT_225_1
MGT_225_2
MGT_225_3
MGT_225_REFCLK_0
MGT_225_REFCLK_1
PCIE_3
Not connected
PCIE_2
PCIE_0
PCIE_1
PCIE_CLK_Q0
BANK 227
MGT_227_0
MGT_227_1
MGT_227_2
MGT_227_3
MGT_227_REFCLK_0
MGT_227_REFCLK_1
FMC_HPC0_DP_0
FMC_HPC0_DP_1
FMC_HPC0_DP_2
FMC_HPC0_DP_3
FMC_HPC0_GBTCLK0
FMC_HPC0_GBTCLK1
