KCU116 Board User Guide 51
UG1239 (v1.2) September 28, 2018 www.xilinx.com
Chapter3: Board Component Descriptions
Table 3-15 lists the USB connector J164 pin assignments.
For more technical information on the CP2105GM and the VCP drivers, see the Silicon Labs
website [Ref 27].
Xilinx UART IP is expected to be implemented in the FPGA logic using IP. See the AXI UART
Lite LogiCORE IP Product Guide (PG142) [Ref 11] for more information.
HDMI Video Output
[Figure 2-1, callout 19]
The KCU116 evaluation board provides HDMI™ video output using an Analog Devices
ADV7511KSTZ-P HDMI transmitter at U5. The HDMI transmitter U5 is connected to XCKU5P
FPGA bank 65 and its output is provided on a Molex 47151-0011 HDMI receptacle at P2. The
ADV7511 supports 1080P 60 Hz, YCbCr 4:2:2 encoding via 18-bit input data mapping.
The KCU116 evaluation board supports these HDMI device interfaces:
• 18 data lines
•Independent VSYNC, HSYNC
• Single-ended input CLK
• Interrupt out pin to FPGA
•I
2
C
• Sony/Philips digital interface format (SPDIF) audio
Table3‐15: USB Connector J164 Pin Assignments
USB Connector (J164) Schematic Net Name CP2105GM (U166)
Pin Name Pin Name
1VBUSUSB_VBUS
2 D_P USB_UART_DATA_P 3 D_P
3 D_N USB_UART_DATA_N 4 D_N
5 GND USB_VBUS_GND
GND 2, 25 GND
