KCU116 Board User Guide 8
UG1239 (v1.2) September 28, 2018 www.xilinx.com
Chapter1: Introduction
°
Dual Quad SPI flash memory
°
Micro-B USB J2 JTAG configuration port (Digilent module)
°
Platform cable header J8 JTAG configuration port
Board Specifications
Dimensions
Height: 6.927 inch (17.59 cm)
Thickness (±5%): 0.061 inch (0.1549 cm)
Length: 9.5 inch (24.13 cm)
Note:
A 3D model of this board is not available.
IMPORTANT: The KCU116 board height exceeds the standard 4.376 inch (11.15 cm) height of a PCI
Express card.
Environmental
Temperature
Operating: 0°C to +45°C
Storage: -25°C to +60°C
Humidity
10% to 90% non-condensing
Operating Voltage
+12 V
DC
