KCU116 Board User Guide 58
UG1239 (v1.2) September 28, 2018 www.xilinx.com
Chapter3: Board Component Descriptions
User I/O
[Figure 2-1, callouts 22, 23, 24, 25]
The KCU116 board provides these user and general purpose I/O capabilities:
• Eight user LEDs (callout 22)
°
GPIO_LED[7-0]: DS44, DS43, DS42, DS41, DS40, DS39, DS37, DS38
• Five user pushbuttons and CPU reset switch (callouts 23, 24)
°
GPIO_SW_[NESWC]: SW18, SW22, SW16, SW14, SW15
°
CPU_RESET: SW17
• 4-position user DIP switch (callout 25)
°
GPIO_DIP_SW[3:0]: SW13
DS54 SYS_1VO On
DS55 SYS_1V8 On
DS57 SYSCTLR Error
EPHY P3 (Right) LED ENET PHY LINK1000 Mode
EPHY P3 (Left) LED ENET PHY Activity
Table3‐19: KCU116 Board Status and User LEDs (Cont’d)
Reference Designator Description
