17
RX-V3300/DSP-AZ2
RX-V3300/DSP-AZ2
• Starting DIAG
Press the “STANDBY/ON” key while simultaneously
pressing those two keys of the main unit as indicated in the
figure below.
●ダイアグの起動
RX-V3300
Keys of main unit
Turn on the power while pressing these keys.
DSP-AZ2
Turn on the power while pressing these keys.
• Starting DIAG in the protection cancel
mode
If the protection function works and causes hindrance to
trouble diagnosis, cancel the protection function as
described below, and it will be possible to enter the DIAG
mode. (The protection functions other than the excess
current detect function will be disabled.)
Press the “STANDBY/ON” key while simultaneously
pressing those two keys indicated in the figure above. At
this time, keep pressing those two keys for 3 seconds or
longer.
In this mode, the “SLEEP” segment of the FL display of the
main unit flashes to indicate that the mode is DIAG mode
with the protection functions disabled.
CAUTION!
Using this product with the protection function disabled
may cause damage to itself. Use special care for this point
when using this mode.
●プロテクション解除モードでの起動
注意！
プロテクションを解除した状態でのダイアグモードは、
危険な状態でもプロテクションが作動しないため、動作
させると、機器を破壊することがあります。このモード
を使用する場合は十分注意してください。
●ダイアグの解除
• Canceling DIAG
[1] Before canceling DIAG, execute setting for PRESET of
DIAG menu No.12 (Memory initialization inhibited or
Memory initialized).
* In order to keep the user memory stored, be sure to
select PRESET INHIBIT (Memory initialization
inhibited). Protection history will remain memory.
[2] Turn off the power by pressing the “STANDBY/ON”
key of the main unit or the “STANDBY” key of the
remote controller.
To Next Page
