RX-V3300/DSP-AZ2
RX-V3300/DSP-AZ2
■ General/総合
Power Supply/電源電圧
U model ............................................................... AC 120 V, 60 Hz
A model ...............................................................AC 240 V, 50 Hz
B, G models ........................................................AC 230 V, 50 Hz
R model .................................... AC 110/120/220/240 V, 50/60 Hz
T model ...............................................................AC 220 V, 50 Hz
K model ....................................................... AC 110/220 V, 60 Hz
J model ........................................................... AC 100V, 50/60 Hz
Power Consumption/消費電力
U model ................................................................ 500 W / 640 VA
A, B, G, R, T, K models ...................................................... 500 W
J model ................................................................................ 430 W
Standby Power Consumption (reference data)/待機電力(参考値)
U, A, B, G, T, K, J models ...................................................... 1 W
R model ................................................................................ 1.2 W
Maximum Power Consumption/最大消費電力
(6ch Drive, 10% THD)
R model ............................................................................. 1100 W
AC Outlets/ACアウトレット
2 switched outlets
U, G, J models ................................................. 100 W max. total
R, T models ........................................................ 50 W max. total
1 switched outlet
A, B models ............................................................... 100W max.
Dimensions/寸法 (W x H x D)
...................... 435 x 191 x 453 mm (17-1/8" x 7-1/2" x 17-13/16")
Weight/重量
.................................................................... 22.0 kg (48 lbs. 8 oz.)
Finish/仕上げ
RX-V3300 .............................. Black color (U, A) models
DSP-AZ2 ............................... Gold color (R, T, K, J) model
Black color (B, G, R) models
Titan color (G) model
Accessories/付属品
Remote Control, Batteries (Alkaline Dry), Power Cable (U, G, R, T,
K, J models), Indoor FM Antenna (U, A models), AM Loop
Antenna (U, A models)
* Specifications are subject to change without notice due to product
improvements.
※ 参考仕様および外観は予告なく変更されることがあります。
U .......... U.S.A. model A ...... Australian model
B .......... British model G ...... European model
R .......... General model T ....... Chinese model
K .......... Korean model J ....... Japanese model
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks of
Dolby Laboratories.
ドルビーラボラトリーズからの実施権に基づき製造されていま
す。ドルビー、DOLBY、ドルビーデジタル、PROLOGICおよび
ダブルD記号 は、ドルビーラボラトリーズの商標です。
“DTS”, “DTS-ES Extended Surround” and “Neo: 6” are
trademarks of Digital Theater Systems, Inc.
DTS、DTS-ESExtendedサラウンドおよびNeo:6はデジタルシア
ターシステムズの登録商標です。
AACロゴマーク はドルビーラボラトリーズの商標です。
• Set Menu Table/セットメニュー
No. SET MENU PRESET VALUE SETTING RANGES
1. SPEAKER SET
1A CENTER SPEAKER LARGE LARGE, SMALL, NONE
1B MAIN SPEAKER LARGE LARGE, SMALL
1C REAR L/R SPEAKER LARGE LARGE, SMALL, NONE
1D REAR CENTER SPEAKER LARGE LARGE, SMALL, NONE
1E LFE/BASS OUT BOTH SUBWOOFER, MAIN, BOTH
1F FRONT EFFECT SPEAKER YES YES, NONE
1G MAIN LEVEL NORMAL NORMAL, –10dB
1H SP B SET MAIN MAIN, ZONE B
2. LOW FREQ. TEST TEST TONE : OFF OFF, ON
OUTPUT : MAIN L/R MAIN L/R, L, C, R, RS, RC, LS, SWFR
FREQ. : 88Hz 35Hz/ ••• /88Hz/ ••• /WIDE
3. L/R BALANCE CENTER L, ••• , CENTER, ••• , R (40 steps)
4. HP TONE CONTROL HP BASS : 0dB –6dB — +3dB (1dB step)
HP TREBLE : 0dB –6dB — +3dB (1dB step)
5. CENTER GRAPHIC EQ. 100Hz : 0dB –6dB — +6dB (1dB step)
300Hz : 0dB –6dB — +6dB (1dB step)
1kHz : 0dB –6dB — +6dB (1dB step)
3kHz : 0dB –6dB — +6dB (1dB step)
10kHz : 0dB –6dB — +6dB (1dB step)
6. INPUT RENAME DVD (Currently selected input)
