• Details of DIAG menu
With full-bit output specified in some modes, it is possible
to execute 0dBFS output without head margin in each
channel.
1. YSS938
This function is for YSS938 only. Main DSP of YSS938
is selected for MAIN L/R output.
Using the sub-menu, it is possible to select the analog
bypass, 0dB output level or full-bit output.
ANALOG BYPASS
• The signal is output through the signal path as shown
below.
• The signal for L/R is output as it is without passing
through the DSP section.
Reference data
INPUT: DVD ANALOG
SUBWOOFER: 50Hz, Others: 1kHz
●ダイアグメニュー詳細
1. YSS938
ANALOGBYPASS
YSS 0dB
• The signal is output including the head margin.
Head margin:
Main L/R: 0dBFS, Center: -6dBFS, Rear Center:
-6dBFS, FL/FR: -6dBFS, RL/RR: -12dBFS, SWFR: Add
L/R signal at -20dBFS.
YSS0dB
Reference data
INPUT: DVD ANALOG
SUBWOOFER: 50Hz, Others: 1kHz
Input level Volume
PRE OUTPUT
MAIN L/R FRONT L/R CENTER REAR L/R
REAR CENTER
SUBWOOFER
Both ch, -20 dBV -10 dB -13.0 dBV -14.8 dBV -13.5 dBV -13.6 dBV -13.6 dBV +2.8 dBV
Input level Volume
PRE OUTPUT
MAIN L/R FRONT L/R CENTER REAR L/R
REAR CENTER
SUBWOOFER
Both ch, -20 dBV -10 dB -13.6 dBV -14.8 dBV -13.5 dBV -13.6 dBV -13.6 dBV +2.8 dBV
