Yamaha F100B - Page 115

60C5D11
5-22
1
2
3
4
5
6
7
8
9
È
Tightening sequence
No. Part name Q’ty Remarks
1 Cylinder head cover 1
2 Camshaft 2
3 Camshaft cap 2
4 Camshaft cap 8
5 Fuel pump bracket 1
6 Oil filler cap 1
7 O-ring 1 3.1
×
30.6 mm
8 Bolt 14 M6
×
30 mm
9 Gasket 1
Not reusable
10 Breather cover 1
11 Screw 8 M4
×
8 mm
12 Bolt 4 M7
×
48 mm
13 Bolt 16 M7
×
37 mm
14 Oil seal 2
Not reusable
15 Bolt 2 M7
×
48 mm
Cylinder head
