Yamaha F100B - Checking the Timing Belt and Sprockets

60C5D11
5-18
1
2
3
4
5
6
7
8
9
NOTE:
Do not turn the camshaft when loosening the
driven sprocket bolt.
6. Remove the nut
1
, drive sprocket
A
,
retaining plate
B
, and Woodruff key
C
.
Checking the timing belt and
sprockets
1. Check the interior and exterior of the tim-
ing belt for cracks, damage, or wear.
Replace if necessary.
2. Check the drive sprocket
1
and driven
sprockets
2
for cracks, damage, or
wear. Replace if necessary.
Installing the sprockets and timing
belt
1. Check that “” marks
a
and
b
on the
driven sprockets
1
are aligned, and then
tighten the bolts
2
.
2. Install the retaining plate
3
, Woodruff
key
4
, drive sprocket
5
, and nut
6
, and
then tighten the nut.
Flywheel holder: 90890-06522
S60C5200
S60C5220
S60C5230
E
Timing belt and sprockets
