Yamaha F100B - Removing and Installing the Oil Filter; Disassembling the Cylinder Body

POWR
Power unit
5-39
60C5D11
Removing and installing the oil filter
1. Place a rag under the oil filter, and then
remove the filter.
NOTE:
Be sure to clean up any oil spills.
2. Apply a thin coat of engine oil to the O-
ring of the new oil filter.
3. Install the oil filter, and then tighten it to
the specified torque.
Disassembling the cylinder body
1. Remove the exhaust cover bolts in the
sequence shown.
2. Remove the crankcase bolts in the
sequence shown.
Oil filter wrench: 90890-01426
Oil filter wrench: 90890-01426
S60C5770
S60C5780
E
T
R
.
.
Oil filter: 18 N·m (1.8 kgf·m, 13 ft·lb)
S60C5800
S60C5810
