Yamaha F100B - Page 131

60C5D11
5-38
1
2
3
4
5
6
7
8
9
È
Tightening sequence
No. Part name Q’ty Remarks
1 Exhaust cover 1
2 Oil filter 1
3 Gasket 1
Not reusable
4Bolt 1
5 Gasket 1
Not reusable
6 Gasket 1
Not reusable
7 Thermo sensor 1
8 Retainer 1
9Bolt 2 M6
×
16 mm
10 Clamp 1
11 Bolt 1 M6
×
10 mm
12 Gasket 1
Not reusable
13 Grommet 1
14 Pressure control valve 1
15 Spring 1
16 Cover 1
17 Bolt 3
18 Grommet 1
19 Anode 1
20 Cover 1
21 Bolt 2 M8
×
25 mm
22 Bolt 1 M6
×
20 mm
23 Bolt 18 M6
×
30 mm
Cylinder body
