Yamaha F100B - Installing the Pump Housing

BRKT
Bracket unit
7-41
60C5D11
6. Install the new O-ring
D
to the down-
relief valve
E
.
7. Install the filters
F
and down-relief valve
E
into the pump housing as shown.
Installing the pump housing
1. Install the ball
1
and pin
2
into the valve
seat
3
.
2. Install the valve seat
3
, new O-rings
4
,
and valve pin
5
into the cylinder body.
NOTE:
When installing the valve seat assembly,
make sure that the pin is on the tilt cylinder
side as shown.
3. Install the pump housing
6
to the cylin-
der body, and then tighten the bolts
7
to
the specified torque.
4. Install the new O-rings
8
and
9
, and
backup ring
0
to the manual valve
A
.
5. Install the manual valve
A
to the pump
housing, tighten it to the specified torque,
and then install the circlip
B
.
6. Install the new O-ring
C
and reservoir
D
to the cylinder body, and then tighten the
bolts
E
to the specified torque.
7. Install the new O-ring
F
into the reser-
voir cap
G
, and then tighten the reservoir
cap finger tighten to the reservoir.
T
R
.
.
Pump housing bolt
7
:
9 N·m (0.9 kgf·m, 6.5 ft·lb)
Manual valve
A
:
3 N·m (0.3 kgf·m, 2.2 ft·lb)
T
R
.
.
Reservoir bolt
E
:
5 N·m (0.5 kgf·m, 3.6 ft·lb)
S60C7560
