Yamaha F100B - Installing the Tilt Ram

60C5D11
7-36
1
2
3
4
5
6
7
8
9
Installing the tilt ram
1. Fill the tilt cylinder
a
with the recom-
mended fluid to the correct level as
shown.
2. Add a small amount of the recommended
fluid through the cylinder body hole
b
as
shown.
3. Install the tilt piston assembly into the tilt
cylinder, and then tighten the tilt cylinder
end screw
1
to the specified torque.
WARNING
To prevent the power trim and tilt fluid
from spurting out due to internal pres-
sure, the tilt ram should be kept at full
length.
NOTE:
Place the tilt cylinder end screw at the bottom
of the tilt ram and install the tilt piston assem-
bly into the tilt cylinder.
Recommended power trim and tilt
fluid:
ATF Dexron
II
S60C7590
Trim & tilt wrench: 90890-06548
T
R
.
.
Trim cylinder end screw:
130 N·m (13 kgf·m, 94 ft·lb)
Tilt cylinder and trim cylinder (F100B)
