Yamaha F100B - Adjusting the Trim Sensor Cam

60C5D11
7-28
1
2
3
4
5
6
7
8
9
3. Install the power trim and tilt unit. For
installation procedures, see “Installing
the power trim and tilt unit” in this chap-
ter.
4. Inject grease into all grease nipples until
grease comes out from the bushings
a
.
Adjusting the trim sensor cam
1. Fully tilt the outboard motor down.
2. Loosen the screw
1
.
3. Adjust the position of the trim sensor cam
2
until the specified resistance is
obtained.
4. Tighten the screw
1
.
5. Fully tilt the outboard motor up, and then
support it with the tilt stop lever.
WARNING
After tilting up the outboard motor, be
sure to support it with the tilt stop lever.
Otherwise, the outboard motor could sud-
denly lower if the power trim and tilt unit
should lose fluid pressure.
6. Measure the trim sensor resistance.
Check the trim sensor if out of specifica-
tion.
T
R
.
.
Self-locking nut
4
:
15 N·m (1.5 kgf·m, 11 ft·lb)
S60C7170
AA
AA
S60C7175
AA
S60C7185
Gy
P
B
Trim sensor resistance:
Pink (P) – Black (B)
9–11
Ω
at 20 °C (68 °F)
T
R
.
.
Trim sensor cam screw
1
:
2 N·m (0.2 kgf·m, 1.4 ft·lb)
Trim sensor resistance:
Pink (P) – Black (B)
238.8–378.8
Ω
at 20 °C (68 °F)
Clamp brackets (F100B)
