60C5D11
5-52
1
2
3
4
5
6
7
8
9
5. Connect the pilot water hose
0
and
install the engine oil dipstick
A
.
6. Connect the shift cable
B
and throttle
cable
C
, and then adjust their lengths.
For adjustment procedures, see Chapter
3, “Checking the throttle cable opera-
tion,” and “Checking the gearshift opera-
tion.”
7. Connect the fuel hose
D
.
8. Install the grommet
E
and retaining plate
F
.
9. Install the Woodruff key
G
.
10. Install the flywheel magnet and flywheel
magnet cover.
CAUTION:
Apply force in the direction of the arrows
shown, to prevent the flywheel holder
from slipping off easily.
NOTE:
Apply engine oil to the flywheel magnet nut
before installation.
S60C5B80
S60C5B90
Flywheel holder: 90890-06522
