Yamaha F100B - Page 179

60C5D11
6-32
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Lower unit 1
2 Plastic tie 1
Not reusable
3 Hose 1 7
×
200 mm
4 Check screw 1
5 Gasket 2
Not reusable
6 Bolt 4 M10
×
40 mm
7 Drain screw 1
8 Dowel pin 2
9Grommet 1
10 Bolt 1 M8
×
45 mm
11 Trim tab 1
12 Bolt 1 M8
×
60 mm
13 Spacer 1
14 Propeller 1
15 Washer 1
16 Spacer 1
17 Propeller nut 1
18 Cotter pin 1
Not reusable
Lower unit (F100C)
