Yamaha F100B - Page 181

60C5D11
6-34
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Shift rod 1
2 O-ring 1
Not reusable
1.9
×
10.6 mm
3 Oil seal 1
Not reusable
4Bolt 2 M6
×
16 mm
5 Oil seal housing 1
6 O-ring 1
Not reusable
3.1
×
55.6 mm
7 Circlip 1
8Screw 2
9 Cover 1
10 Bolt 2 M8
×
75 mm
11 Bolt 2 M8
×
50 mm
12 Seal 1
13 Water pump housing 1
14 Inner plate cartridge 1
15 Insert cartridge 1
16 Impeller 1
17 Dowel pin 2
18 Gasket 1
Not reusable
19 Outer plate cartridge 1
20 Gasket 1
Not reusable
21 Oil seal housing 1
22 O-ring 1
Not reusable
3.1
×
52.4 mm
23 Gasket 1
Not reusable
24 Oil seal 2
Not reusable
25 Woodruff key 1
Lower unit (F100C)
