Yamaha F100B - Page 199

60C5D11
6-52
1
2
3
4
5
6
7
8
9
4. Install the trim tab
2
to its original posi-
tion, and then connect the speedometer
hose
3
.
5. Install the propeller and propeller nut,
and then tighten the nut finger tight.
Place a block of wood between the anti-
cavitation plate and propeller to keep the
propeller from turning, and then tighten
the nut to the specified torque.
WARNING
Do not hold the propeller with your hands
when loosening or tightening it. Be sure
to remove the battery leads from the bat-
teries and the engine shut-off switch. Put
a block of wood between the anti-cavita-
tion plate and propeller to keep the pro-
peller from turning.
NOTE:
If the grooves in the propeller nut
4
do not
align with the cotter pin hole, tighten the nut
until they are aligned.
T
R
.
.
Mounting bolt:
39 N·m (3.9 kgf·m, 28 ft·lb)
S60C6585
M
M
LT
572
S60C6590
LT
572
T
R
.
.
Propeller nut
4
:
34 N·m (3.4 kgf·m, 25 ft·lb)
Drive shaft and lower case (F100C)
