Yamaha F100B - Page 213

60C5D11
7-6
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Tiller handle sub assembly 1
2 Screw 2 M6
×
10 mm
3 Shift lever cover 1
4Bolt 1 M8
×
40 mm
5 Shift lever 1
6 Bushing 1
7 Washer 1
8 Bushing 2
9Nut 1
10 Engine shut-off switch 1
11 Nut 1
12 Washer 1
13 Bracket 1
14 Collar 1
15 Wave washer 1
16 Washer 1
17 Bolt 1 M10
×
80 mm
18 Connector 2
19 Engine start switch housing 1
20 Engine start switch 1
21 Nut 1
22 Bolt 1 M6
×
25 mm
23 Screw 1
24 Bolt 1 M6
×
20 mm
25 Cover 1
26 Power trim and tilt switch 1
27 Screw 7 M6
×
16 mm
28 Screw 2 M6
×
40 mm
29 Throttle grip 1
30 Screw 1 M5
×
25 mm
31 Washer 1
32 Spring 1
33 Bushing 1
Tiller handle
