Yamaha F100B - Page 215

60C5D11
7-8
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Tiller handle 1
2 Cotter pin 1
Not reusable
3 Friction adjusting knob 1
4Grommet 1
5 Plastic tie 2
Not reusable
6 Cable clamp 1
7Stay 1
8Bolt 1 M6
×
14 mm
9 Throttle cable 1 Short
10 Clip 1
11 Throttle arm 1
12 Throttle arm shaft 1
13 Shift cable 1 Long
14 Shift cable bracket 1
15 Bolt 1 M6
×
20 mm
16 Clip 1
17 Frame 1
18 Screw 2 M5
×
14 mm
19 Bolt 1 M6
×
14 mm
20 Spring housing 1
21 Spring 1
22 Actuator 1
23 Roller 1
24 Bushing 1
25 Shift arm 1
26 Bolt 2 M6
×
30 mm
27 Throttle shaft 1
28 Friction piece 1
29 Nut 1
Tiller handle
