Yamaha F100B - Page 229

60C5D11
7-22
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Steering arm 1
2 Washer 1
3 Bushing 2
4 Swivel bracket 1
5 O-ring 1
Not reusable
5.6
×
48.2 mm
6 Bushing 1
7 Washer 1
8 Steering yoke 1
9 Circlip 1
10 Steering hook 1
11 Nut 2
12 Starboard tilt stop lever 1
13 Bushing 2
14 Port tilt stop lever 1
15 Nut 2
16 Trim stopper 2 M10
×
27 mm
17 Pin 2
18 Tilt stop lever joint 1
19 Bushing 2
20 Collar 1
21 Spring 1
22 Spring holder 1
23 Bolt 1 M6
×
10 mm
Swivel bracket and steering arm (F100B)
