Yamaha F100B - Page 233

60C5D11
7-26
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Swivel bracket assembly 1
2 Starboard clamp bracket 1
3 Port clamp bracket 1
4 Self-locking nut 1
5 Grease nipple 6
6 Ground lead 1
7 Washer 1
8 Screw 1 M6
×
11 mm
9 Washer 2
10 Bushing 2
11 Trim sensor 1
12 Screw 2 M6
×
15 mm
13 Trim sensor cam 1
14 Screw 1 M6
×
24 mm
15 Clamp 1
16 Ground lead 1
17 Bolt 1 M6
×
20 mm
18 Anode 1
19 Bracket 2
20 Ground lead 1
21 Bolt 4 M6
×
30 mm
22 Through tube 1
23 Bolt 1 M8
×
20 mm
24 Cap 1
Clamp brackets (F100B)
