BRKT
Bracket unit
7-31
60C5D11
Tilt cylinder and trim cylinder (F100B)
7
No. Part name Q’ty Remarks
1Tilt ram 1
2 Trim piston assembly 2
3 Cylinder body 1
4 Free piston 1
5 Backup ring 1
6 O-ring 1
Not reusable
7 Dust seal 2
Not reusable
8 Seal 2
Not reusable
9 Trim cylinder end screw 2
10 O-ring 2
Not reusable
11 Backup ring 2
12 O-ring 2
Not reusable
13 Dust seal 1
Not reusable
14 Tilt cylinder end screw 1
15 O-ring 1
Not reusable
16 O-ring 1
Not reusable
17 Tilt piston 1
18 O-ring 1
Not reusable
19 O-ring 1
Not reusable
1
18
19
16
15
13
AA
AA
T
R
.
.
80 N
•
m (8.0 kgf
•
m, 58 ft
•
Ib)
T
R
.
.
100 N
•
m (10 kgf
•
m, 72 ft
•
lb)
T
R
.
.
130 N
•
m (13 kgf
•
m, 94 ft
•
lb)
13
14
15
16
17
18
19
5
6
4
5
6
3
12
11
2
10
8
7
7
8
9
12
11
S60C7365
