Yamaha F100B - Page 245

60C5D11
7-38
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Manual valve 1
2Bolt 2 M5
×
16 mm
3Ball 2
4 Shuttle piston 2
5 O-ring 2
Not reusable
6Main valve 2
7Ball 2
8Bolt 1 M8
×
85 mm
9Bolt 2 M8
×
24 mm
10 Circlip 1
11 O-ring 1
Not reusable
12 O-ring 1
Not reusable
13 Backup ring 1
14 Spring 1
15 Absorber valve pin 1
16 Ball 1
17 Up-relief valve seat 1
18 O-ring 1
Not reusable
19 O-ring 5
Not reusable
20 Ball 1
21 Pin 1
22 Valve seat 1
23 Down-relief valve 1
24 O-ring 1
Not reusable
25 Filter 2
26 Valve pin 1
Gear pump (F100B)
