Yamaha F100B - Page 263

60C5D11
7-56
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Muffler assembly 1
2 Upper case 1
3 Bolt 2 M12
×
194 mm
4 Washer 4
5Plate 1
6 Upper mount 1
7Bolt 3 M8
×
45 mm
8Grommet 1
9Bolt 4 M8
×
40 mm
10 Muffler seal 1
11 Rubber seal 1
12 Gasket 1
Not reusable
13 Screw 2 M6
×
15 mm
14 Baffle plate 1
15 Damper 1
16 Grommet 1
17 Dowel pin 2
18 Bolt 2 M12
×
200 mm
19 Washer 4
20 Rubber washer 2
21 Lower mount 2
22 Washer 2
23 Drive shaft bushing 1
24 Circlip 1
25 Mount cover 2
26 Bolt 4 M10
×
40 mm
Upper case (F100C)
