Yamaha F100B - Page 265

60C5D11
7-58
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Exhaust guide 1
2 Dowel pin 2
3 Gasket 1
Not reusable
4 Gasket 1
Not reusable
5Oil strainer 1
6Collar 3
7Bolt 3 M6
×
25 mm
8 Bolt 12 M6
×
25 mm
9Oil pan 1
10 Gasket 1
Not reusable
11 Exhaust manifold 1
12 Bolt 4 M6
×
70 mm
13 Exhaust seal 1
14 Gasket 2
Not reusable
15 Plate 1
16 Dowel pin 2
17 Bolt 6 M6
×
30 mm
18 Muffler 1
19 Bolt 1 M6
×
50 mm
20 Grommet 1
21 Pipe 1
22 Rubber seal 1
Upper case (F100C)
