60C5D11
7-72
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Power trim and tilt motor 1
2 Pump housing assembly 1
3 Tilt cylinder end screw 1
4 Trim cylinder assembly 1
5 Tilt cylinder assembly 1
6Bolt 4 M6
×
20 mm
7 O-ring 1
Not reusable
8 Joint 1
9Bolt 3 M6
×
75 mm
10 Reservoir cap 1
11 O-ring 1
Not reusable
1.9
×
12.6 mm
12 O-ring 4
Not reusable
1.5
×
8.5 mm
13 Ball 6
14 O-ring 1
Not reusable
15 Free piston 1
16 Valve seal 1
17 Circlip 1
18 Circlip 1
Not reusable
19 Trim cylinder base 1
20 Spring 2
21 Plate 1
22 Circlip 1
Tilt cylinder and trim cylinder (F100C)
