Yamaha F100B - Page 281

60C5D11
7-74
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Trim cylinder 1
2Tilt ram 1
3 Dust seal 1
Not reusable
4 Backup ring 1
5 O-ring 1
Not reusable
2.4
×
22.6 mm
6 Tilt cylinder end screw 1
7 O-ring 1
Not reusable
8 Backup ring 1
9 O-ring 1
Not reusable
2.4
×
22.6 mm
10 Trim cylinder end screw 1
11 O-ring 1
Not reusable
12 Plate 1
13 Filter 1
14 O-ring 1
Not reusable
15 Trim piston 1
16 Backup ring 1
17 O-ring 1
Not reusable
18 Ball 5
19 Absorber valve pin 5
20 Spring 5
21 Plate 1
22 Ball 1
23 O-ring 1
Not reusable
3.5
×
35.7 mm
24 Backup ring 1
25 Tilt piston 1
26 Ball 4
27 Absorber valve pin 4
28 Spring 4
29 Pin 4
30 Pin 2
31 Washer 1
32 Bolt 1 M12
×
45 mm
Tilt cylinder and trim cylinder (F100C)
