Yamaha F100B - Page 289

60C5D11
7-82
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Circlip 1
2 Manual valve 1
3 O-ring 1
Not reusable
2.4
×
22.6 mm
4 Manual release spring 1
5 Manual release pin 1
6 Circlip 1
7Ball 1
8 Manual valve seat 1
9 O-ring 1
Not reusable
1.5
×
8.5 mm
10 Pump housing 1
11 Main valve 2
12 O-ring 2
Not reusable
13 O-ring 2
Not reusable
14 Shuttle piston 1
15 O-ring 1
Not reusable
1.9
×
12.6 mm
16 Main valve 1
17 O-ring 1
Not reusable
18 O-ring 1
Not reusable
19 O-ring 1
Not reusable
20 Valve seat 2
21 Spring 1
22 Relief valve seat 1
23 O-ring 1
Not reusable
1.9
×
10.6 mm
24 Filter 1
25 O-ring 1
Not reusable
1.9
×
9.6 mm
Gear pump (F100C)
