3. Install the manual valve seat
6
, and then
tighten it to the specified torque.
4. Install the manual valve
7
, and then
tightening it to the specified torque.
5. Install the relief valve seal
8
, relief valve
seat
9
, and absorber valve pin
0
.
6. Tighten the cap
A
into the relief valve
seat to the specified depth
a
.
7. Install the gear pump
B
by installing the
bolts
C
, then tightening them to the
specified torque.
T
R
.
.
Manual valve seat
6
:
4 N·m (0.4 kgf·m, 2.9 ft·lb)
Manual valve
7
:
2 N·m (0.2 kgf·m, 1.4 ft·lb)
S60C7845
S60C7850
Depth
a
: 2.2 mm (0.087 in)
T
R
.
.
Gear pump bolt
C
:
8 N·m (0.8 kgf·m, 5.8 ft·lb)
S60C7855
