Yamaha F100B - Page 45

60C5D11
2-10
1
2
3
4
5
6
7
8
9
Symbol Unit
Model
F100BET F100CET
L1 mm (in) 664 (26.1) 647 (25.5)
L2 mm (in) 161 (6.3) 171 (6.7)
L3 mm (in) —
L4 mm (in) 631 (24.8) 574 (22.6)
L5 (L) mm (in) 69 (2.7) 65 (2.6)
(X) mm (in) 76 (3.0)
L6 (L) mm (in) 1,005 (39.6) 998 (39.3)
(X) mm (in) 1,122 (44.2) 1,115 (43.9)
L7 mm (in) 536 (21.1) 528 (20.8)
L8 mm (in) 158 (6.2) 164 (6.5)
L9 (L) mm (in) 25 (1.0) 27 (1.1)
(X) mm (in) 25 (1.0) 27 (1.1)
L10 mm (in) 75 (3.0) 62 (2.4)
H1 (L) mm (in) 929 (36.6) 917 (36.1)
(X) mm (in) 1,056 (41.6) 1,040 (40.9)
H2 mm (in) 667 (26.3) 666 (26.2)
H3 mm (in) 191 (7.5)
H4 (L) mm (in) 516 (20.3) 537 (21.1)
(X) mm (in) 643 (25.3) 664 (26.1)
H5 mm (in) —
H6 (L) mm (in) 776 (30.6) 767 (30.2)
(X) mm (in) 854 (33.6) 844 (33.2)
H7 mm (in) 388 (15.3) 366 (14.4)
H8 mm (in) 14 (0.6) 27 (1.1)
H9 mm (in) 877 (34.5) 856 (33.7)
H10 mm (in) 44 (1.7) 48 (1.9)
H11 mm (in) 25 (1.0) 24 (0.9)
W1 mm (in) 243 (9.6) 240 (9.4)
W2 mm (in) —
W3 mm (in) —
W4 mm (in) —
W5 mm (in) 384 (15.1) 405 (15.9)
W6 mm (in) —
A1 Degree 30 35
A2 Degree 70
A3 Degree 4
T1 mm (in) 660 (26.0)
Maintenance specifications
