Yamaha F100B - Page 50

SPEC
Specifications
2-15
60C5D11
Lower unit (F100B)
Check screw — 70.75.1
Lower unit bolt M10 39 3.9 28
Drain screw — 70.75.1
Propeller nut — 55 5.5 40
Trim tab bolt M10 42 4.2 30
Ring nut — 103 10.3 74
Pinion nut — 93 9.3 67
Water inlet cover screw — 40.42.9
Lower unit (F100C)
Check screw — 70.75.1
Lower unit bolt M10 39 3.9 28
Drain screw — 70.75.1
Propeller nut — 34 3.4 25
Ring nut — 103 10.3 74
Pinion nut — 93 9.3 67
Water inlet cover screw — 50.53.6
Bracket unit
Tiller handle assembly nut — 37 3.7 27
Engine shut-off switch nut — 40.42.9
Engine start switch nut — 40.42.9
Tiller handle bracket bolt M10 37 3.7 27
Oil pump assembly bolt M6 11 1.1 8.0
Oil pump cover screw M6 4 0.4 2.9
Upper mount nut — 53 5.3 38
Lower mount nut
F100B — 73 7.3 53
F100C — 53 5.3 38
Upper mount bolt M8 26 2.6 19
Muffler assembly bolt M8 20 2.0 14
Baffle plate screw M6 4 0.4 2.9
Oil strainer bolt M6 11 1.1 8.0
Oil pan bolt M6 11 1.1 8.0
Exhaust manifold bolt M6 11 1.1 8.0
Clamp bracket self-locking nut — 15 1.5 11
Trim sensor screw M6 2 0.2 1.4
Part to be tightened Thread size
Tightening torques
N·mkgf·mft·lb
