Yamaha F100B - Page 77

60C5D11
4-6
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Screw 3 M6
×
35 mm
2 Cover 1
3 Fuel pump body 2 1
4 Fuel pump body 1 1
5 Plunger 1
6Spring 1
7Nut 3
8Spring 1
9Pin 1
10 Diaphragm 1
11 Nut 2
12 Spring 2
13 Valve 2
14 Screw 2
15 Gasket 1
Not reusable
Fuel pump
