Yamaha F100B - Page 81

60C5D11
4-10
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Throttle cam 1
2 Throttle link rod 1
3 Throttle position sensor 1
4Bracket 1
5 Throttle control lever 1
6Bracket 1
7 Washer 1
8Spring 1
9 Washer 1
10 Wave washer 1
11 Collar 1
12 Bolt 1 M6
×
35 mm
13 Bolt 1 M6
×
12 mm
14 Washer 1
15 Wave washer 1
16 Washer 1
17 Collar 1
18 Bolt 2 M6
×
25 mm
19 Collar 1
20 Pin 1
21 Spacer 1
22 Screw 2 M5
×
25 mm
23 Screw 2 M5
×
10 mm
Throttle control
