Yamaha F100B - Page 83

60C5D11
4-12
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Silencer 1
2 Carburetor assembly 1
3 Intake manifold 1
4 Acceleration pump 1
5 Blowby hose 1
6Bolt 8 M6
×
20 mm
7Bolt 3 M8
×
60 mm
8 O-ring 4
Not reusable
3.5
×
47.7 mm
9 Gasket 1
10 Bolt 8 M6
×
120 mm
11 Spacer 4
12 O-ring 4
Not reusable
13 Fuel hose 2 Carburetor-to-carburetor
14 Link lever 1
15 O-ring 4
Not reusable
16 Spacer 4
17 O-ring 4
Not reusable
2.4
×
44.5 mm
18 Bolt 5 M8
×
35 mm
19 Fuel filter 4
20 Clip 8
21 Fuel hose 2 Carburetor-to-fuel pump
10
×
120 mm
22 Fuel hose 1 Carburetor-to-fuel pump
10
×
180 mm
23 Fuel hose 1 Carburetor-to-fuel pump
10
×
350 mm
24 Screw 2 M6
×
15 mm
25 Hose 7 Carburetor-to-carburetor
26 Hose 1 Carburetor-to-acceleration pump
27 Hose 2 Check valve-to-carburetor
28 Check valve 1
Throttle control
