Yamaha F100B - Page 85

60C5D11
4-14
1
2
3
4
5
6
7
8
9
È
Carburetors #1 and #3
É
Carburetor #2
Ê
Carburetor #4
No. Part name Q’ty Remarks
1 Carburetor body 1
2 Screw 3 M4
×
10 mm
3 Cover 1
4 Gasket 1
Not reusable
5Spring 1
6 O-ring 1
Not reusable
7 Pilot screw 1
8Prime Start 1
9 Screw 1 M4
×
10 mm
10 Bracket 1
11 O-ring 1
Not reusable
12 Body 1
13 Screw 3 M5
×
16 mm
14 O-ring 4
Not reusable
15 O-ring 1
Not reusable
16 Valve seat 1
17 Needle valve 1
18 Pilot jet 1
19 Plug 1
20 Main nozzle 1
21 Main jet 1
22 Screw 1 M4
×
8 mm
23 Float 1
24 Float pin 1
25 Gasket 1
Not reusable
26 Float chamber 1
27 O-ring 1
Not reusable
28 Drain screw 1
29 Screw 4 M4
×
14 mm
Carburetor
