Yamaha MX775 - DIMENSIONS

DIMENSIONS
1-2
1
2
3
4
5
6
7
8
9
10
GENERAL INFORMATION
DIMENSIONS
TOP
MOUNTING BASE
*1: UNC: Unified coarse thread (Unit: in)
*2: PCD: Pitch Circle Diameter
mm (in)
mm (in)
157.1(6.19)
499.2(19.65）
35°
35°
45°
45°
PCD 254
4 3/8-16UNC
