Yamaha MX775 - MUFFLER

3-4
1
2
3
4
5
6
7
8
9
10
ENGINE
MUFFLER (For models equipped with a muffler)
MUFFLER (For models equipped with a muffler)
Order Job/Parts to remove Q’ty Remarks
Removing the muffler Remove the parts in the order listed.
1 Muffler 1
2 Spark arrester 1
3Gasket 2
4
O
2
sensor
1
1
2
3
3.5 N・m (0.35 kgf・m, 2.5 lb・ft)
20 N・m (2.0 kgf・m, 14 lb・ft)
20 N・m (2.0 kgf・m, 14 lb・ft)
18 N・m (1.8 kgf・m, 13 lb・ft)
4
