Yamaha MX775 - REPLACING THE ENGINE OIL

2-6
1
2
3
4
5
6
7
8
9
10
PERIODIC CHECKS AND ADJUSTMENTS
PERIODIC MAINTENANCE
Oil warning light comes on  Add oil.
Oil warning light does not comes on  OK
REPLACING THE ENGINE OIL
1. Warm up the engine for several minutes, and then
stop the engine.
Place the oil pan under the engine.
2. Remove:
• Oil filler cap
• Oil drain bolt “1”
• Oil drain bolt gasket “2”
3. Drain:
• Engine oil
4. If the oil filter is also to be replaced, perform the fol-
lowing procedure.
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
a. Remove the oil filter “1” with an oil filter wrench “2”.
b. Lubricate the O-ring “3” of the new oil filter with a
thin coat of engine oil.
Avoid draining the engine oil immediately after stop-
ping the engine. The oil is hot and should be handled
with care to avoid burns.
WARNING
2 1
Oil filter wrench:
YM-01469
Make sure the O-ring “3” is positioned correctly in the
groove of the oil filter.
NOTICE
