PERIODIC CHECKS AND ADJUSTMENTS
PERIODIC MAINTENANCE
2.
Check the areas outside of the engine for oil leakage.
Oil leakage Replace the gasket, oil seal, or O-ring.
ENGINE OIL LEVEL
1.
Remove:
• Oil filler cap “1”
2.
Check:
• Check that engine oil is at the specified level.
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
a. Place the multi-purpose engine on a level surface.
b. Warm up the engine for several minutes.
c. Stop the engine.
d. Remove the oil filler cap.
e. Wipe the engine oil dipstick “1” clean, insert it back
into the oil filler hole (without screwing it in), and
then remove it again to check the oil level.
Add oil if necessary.
The engine oil should be between the minimum “a” and
maximum “b” level marks.
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
3.
Install:
• Oil filler cap
Check whether the oil warning light comes on by turning
the main switch.
