SPECIFICATIONS
MAINTENANCE SPECIFICATIONS
Fuel line pressure (at idle) 255–285 kPa (2.55–2.85 kgf/cm², 36.98–41.33 psi)
Fuel injector:
Resistance 11.4–12.6
Oil pump:
Inner-rotor-to-outer-rotor-tip
clearance
0.19–0.35 mm (0.008–0.013 in)
Relief valve operating pressure 342–538 kPa (3.42–5.38 kgf/cm², 49.59–78.01 psi)
Throttle body:
ID mark E-3750-2 (MX775)
E-3750-1 (MX800)
E-3750-0 (MX825)
Throttle position sensor:
Output voltage (at idle) 0.95–4.5 V
Resistance 3.0–7.0 k
Governor assembly:
Tension spring attach hole 7
Engine speed:
High engine speed (with no load) 3550–3600 r/min
Low engine speed (with no load) 1450–1550 r/min
