SPECIFICATIONS
TIGHTENING TORQUES
Engine temperature sensor M10  1.5 12 N·m (1.2 kgf·m, 8.7 lb·ft)
Reed valve M6  1.0 10 N·m (1.0 kgf·m, 7.2 lb·ft)
Scroll air shroud bolt M6  1.0 7 N·m (0.7 kgf·m, 5.1 lb·ft)
Low-pressure fuel pump bolt M6  1.0 7 N·m (0.7 kgf·m, 5.1 lb·ft)
High-pressure fuel pump bolt M6  1.0 9 N·m (0.9 kgf·m, 6.5 lb·ft)
Fuel pump bracket M6  1.0 9 N·m (0.9 kgf·m, 6.5 lb·ft)
Throttle body assembly nut M6  1.0 7 N·m (0.7 kgf·m, 5.1 lb·ft)
Governor assembly bolt M6  1.0 8 N·m (0.8 kgf·m, 5.8 lb·ft)
Inlet pipe bolt M6  1.0 9 N·m (0.9 kgf·m, 6.5 lb·ft)
Manifold absolute pressure sensor
bolt
M6  1.0 7 N·m (0.7 kgf·m, 5.1 lb·ft)
Intake manifold nut and bolt M6  1.0
1st: 3.0 N·m (0.30 kgf·m, 2.2 lb·ft)
2nd: 7 N·m (0.7 kgf·m, 5.1 lb·ft)
Starter motor assembly bolt M8  1.25 23 N·m (2.3 kgf·m, 17 lb·ft)
Earth terminal nut M8  1.25 9 N·m (0.9 kgf·m, 6.5 lb·ft)
Starter motor rear bracket bolt M6  0.8 6 N·m (0.6 kgf·m, 4.3 lb·ft)
Starter relay nut M6  1.0 11 N·m (1.1 kgf·m, 8.0 lb·ft)
Item Thread size Tightening torque
