9.10 H: Terminal Functions
632 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No.
(Hex.)
Name Description
Default
(Range)
Ref.
H7-03
(1187)
Expert
Virtual Multi-Function
Input 3
Sets the function that enters the virtual input set in H7-14 [Virtual Multi-Function Output
3].
Note:
Settings 1B [Programming Lockout] and 11B [!Programming Lockout] are not
available.
F
(1 - 1B8)
313
H7-04
(1188)
Expert
Virtual Multi-Function
Input 4
Sets the function that enters the virtual input set in H7-16 [Virtual Multi-Function Output
4].
Note:
Settings 1B [Programming Lockout] and 11B [!Programming Lockout] are not
available.
F
(1 - 1B8)
314
H7-10
(11A4)
Expert
Virtual Multi-Function
Output 1
Sets the function for virtual digital output 1. F
(0 - 1A7)
314
H7-11
(11A5)
Expert
Virtual Output 1 Delay
Time
Sets the minimum ON time for virtual digital output 1. 0.1 s
(0.0 - 25.0 s)
314
H7-12
(11A6)
Expert
Virtual Multi-Function
Output 2
Sets the function for virtual digital output 2. F
(0 - 1A7)
314
H7-13
(11A7)
Expert
Virtual Output 2 Delay
Time
Sets the minimum ON time for virtual digital output 2. 0.1 s
(0.0 - 25.0 s)
314
H7-14
(11A8)
Expert
Virtual Multi-Function
Output 3
Sets the function for virtual digital output 3. F
(0 - 1A7)
314
H7-15
(11A9)
Expert
Virtual Output 3 Delay
Time
Sets the minimum ON time for virtual digital output 3. 0.1 s
(0.0 - 25.0 s)
314
H7-16
(11AA)
Expert
Virtual Multi-Function
Output 4
Sets the function for virtual digital output 4. F
(0 - 1A7)
315
H7-17
(11AB)
Expert
Virtual Output 4 Delay
Time
Sets the minimum ON time for virtual digital output 4. 0.1 s
(0.0 - 25.0 s)
315
H7-30
(1177)
Expert
Virtual Analog Input
Selection
Sets the virtual analog input function. F
(0 - 31)
315
H7-31
(1178)
RUN
Expert
Virtual Analog Input
Gain
Sets the virtual analog input gain. 100.0%
(-999.9 - 999.9%)
315
H7-32
(1179)
RUN
Expert
Virtual Analog Input Bias Sets the virtual analog input bias. 0.0%
(-999.9 - 999.9%)
315
H7-40
(1163)
Virtual Analog Out
Signal Select
Sets the signal level of the virtual analog output.
0 : 0 to 100% (Absolute Value)
1 : -100 to 100%
2 : 0 to 100% (Lower Limit at 0)
0
(0 - 2)
315
H7-41
(1164)
Virtual Analog Output
Function
Sets the monitor to be output from the virtual analog output.
Set the x-xx part of the Ux-xx [Monitor]. For example, set H7-41 = 102 to monitor U1-02
[Output Frequency].
102
(0 - 999)
315
H7-42
(1165)
Virtual Analog Output
FilterTime
Sets the time constant for a primary filter of the virtual analog output. 0.00 s
(0.00 - 2.00 s)
316
