1 Overview of the MP2300
1.2.2 MP2300 Modules
1-4
1.2.2 MP2300 Modules
The following table shows the names and descriptions of the Basic Module and Optional Modules.
Group Name Description Model Remarks
Basic Module
Basic Module MP2300
JEPMC-MP2300-E
JEPMC-MP2300
MECHATROLINK-I,
MECHATROLINK-II
8 input, 4 outputs
Optional
Modules
Motion
Modules
MECHATROLINK
Motion-control Module
SVB-01
JAPMC-MC2310-E
JAPMC-MC2310
MECHATROLINK-I, -II, 16 axes maximum
SVC-01 JAPMC-MC2320-E
MECHATROLINK-III, 16 axes maximum
Analog Output Motion-
control Module
SVA-01
JAPMC-MC2300-E
JAPMC-MC2300
Analog output, 2 axes maximum
Pulse Output Motion-
control Module
PO-01 JAPMC-PL2310-E Pulse output, 4 axes maximum
Multiple-CPU Module
MPU-01 JAPMC-CP2700-E
Optional module (it has both CPU functions
and the functions of a built-in SVC-01.)
I/O Modules
I/O Module
LIO-01
JAPMC-IO2300-E
JAPMC-IO2300
16 inputs, 16 outputs (sink mode output)
1 pulse input
LIO-02
JAPMC-IO2301-E
JAPMC-IO2301
16 inputs, 16 outputs (source mode output)
1 pulse input
LIO-04
JAPMC-IO2303-E
JAPMC-IO2303
32 inputs, 32 outputs (sink mode output)
LIO-05
JAPMC-IO2304-E
JAPMC-IO2304
32 inputs, 32 outputs (source mode output)
LIO-06 JAPMC-IO2305-E
8 inputs, 8 outputs (sink mode output)
Analog input, 1 channel
Analog output, 1 channel
Pulse counter, 1 channel
Analog Input Module AI-01
JAPMC-AN2300-E
JAPMC-AN2300
Analog input, 8 channels
Analog Output Module AO-01 JAPMC-AN2310-E Analog output, 4 channels
Output Module DO-01
JAPMC-DO2300-E
JAPMC-DO2300
64 outputs (sink mode output)
Counter Module CNTR-01 JAPMC-PL2300-E Reversible counter, 2 channels
Communica-
tion
Modules
Ethernet Communica-
tion Module
218IF-01
JAPMC-CM2300-E
JAPMC-CM2300
RS-232C and 10Base-T Ethernet communi-
cation
218IF-02
JAPMC-CM2302-E
JAPMC-CM2302
RS-232C and 100Base-TX/10Base-T
Ethernet communication
General-purpose Serial
Communication Mod-
ule
217IF-01
JAPMC-CM2310-E
JAPMC-CM2310
RS-232C and RS422/485 communication
DeviceNet Communi-
cation Module
260IF-01
JAPMC-CM2320-E
JAPMC-CM2320
RS-232C and DeviceNet communication
PROFIBUS Communi-
cation Module
261IF-01
JAPMC-CM2330-E
JA
PMC-CM2330
RS-232
C and PROFIBUS communication
FL-net Communication
Module
262IF-01 JAPMC-CM2303-E FL-net communication
EtherNet/IP Communi-
cation Module
263IF-01 JAPMC-CM2304-E EtherNet/IP communication
EtherCAT Communica-
tion Module
264IF-01 JAPMC-CM2305-E EtherCAT communication (slave)
CompoNet Communi-
cation Module
265IF-01 JAPMC-CM2390-E CompoNet communication
PROFINET Communi-
cation Module
266IF-01 JAPMC-CM2306-E PROFINET communication (master)
266IF-02 JAPMC-CM2307-E PROFINET communication (slave)
CC-Link Communica-
tion Module
267IF-01 JAPMC-CM23A0-E CC-Link communication (master)
CC-Link IE Field Com-
munication Module
269IF-01 JAPMC-CM2308-E CC-Link IE Field communication (slave)
MPLINK/CP-215
Communication Mod-
ule
215AIF-01
JAPMC-CM2360-E
JAPMC-CM2360
RS-232C, MPLINK, and CP-215 communi-
cation
