1 Overview of the MP2300
1.4.1 Devices Connectable to MECHATROLINK-I/II
1-6
1.4 Devices Connectable to MECHATROLINK
1.4.1 Devices Connectable to MECHATROLINK-I/II
The devices that are compatible with MECHATROLINK-I/II and can be connected to the MP2300 and the
SVB-01 Module are listed below.
( 1 ) Compatible SERVOPACKs
( 2 )
Compatible
Inverters
( 3 ) Compatible Modules
Model Number Details MECHATROLINK-I MECHATROLINK-II
SGD-N
SGDB-AN
MECHATROLINK-I-compatible AC
SERVOPACK
Yes No
SGDH-E
JUSP-NS100
Σ-II Series SGDH SERVOPACK
NS100 MECHATROLINK-I
Application Module
Yes No
SGDH-E
JUSP-NS115
Σ-II Series SGDH SERVOPACK
NS115 MECHATROLINK-II
Application Module
Yes Yes
SGDS-1
Σ-III Series SGDS SERVOPACK
Yes Yes
SGDX-12
SGDX SERVOPACK
Yes Yes
SJDE-AN
SJDE SERVOPACK
No Yes
SGDV-1
SGDV SERVOPACK
Yes Yes
SGD7S-10
SGD7S SERVOPACK
Yes Yes
Model Number Details MECHATROLINK-I MECHATROLINK-II
CIMR-G7A
SI-T
Varispeed G7 Inverter
with MECHATROLINK interface
Yes Yes
CIMR-F7A
SI-T
Varispeed F7 Inverter
with MECHATROLINK interface
Yes Yes
CIMR-V7AA
SI-T/V7
VSmini V7 Inverter
with MECHATROLINK interface
Yes Yes
CIMR-A
SI-T3
High Performance Vector Control Drive A1000
MECHATROLINK-II Option Card
Yes Yes
CIMR-V
SI-T3/V
Compact Vector Control Drive V1000
MECHATROLINK-II Option Unit
Yes Yes
Model Number Details MECHATROLINK-I MECHATROLINK-II
JEPMC-IO350
64-point I/O Module
24 VDC, 64 inputs, 64 outputs (sink)
Yes No
JAMSC-120DDI34330
DC Input Module 12/24 VDC, 16 inputs
Yes No
JAMSC-120DDO34340
DC Output Module 12/24 VDC, 16 outputs
Yes No
JAMSC-120DAI53330
AC Input Module 100 VAC, 8 inputs
Yes No
JAMSC-120DAI73330
AC Input Module 200 VAC, 8 inputs
Yes No
JAMSC-120DAO83330
AC Output Module 100/200 VAC, 8 outputs
Yes No
JAMSC-120DRA83030
Relay Module
Wide voltage range relay contacts, 8 contact
outputs
Yes No
JAMSC-120AVI02030
A/D Module
Analog inputs, -10 to 10 V, 4 channels
Yes No
JAMSC-120AVO01030
D/A Module
Analog outputs, -10 to 10 V, 2 channels
Yes No
JAMSC-120EHC21140
Counter Module
Reversible counter, 2 channels
Yes No
JAMSC-120MMB20230
Pulse Output Module, Pulse output, 2 channels
Yes No
