3.7 Forming a Protective Sequence
129
2) Contact Output Signal ALM+, ALM-
Output → ALM+ 1CN-31
Servo Alarm Output For Speed Torque
Control and
Position Control
Output → ALM- 1CN-32
Signal Ground for Servo
Alarm Output
For Speed Torque
Control and
Position Control
Signal ALM+ is output when the Servopack de-
tects an alarm.
Form an external circuit so that this alarm output
(ALM) turns the Servopack main power OFF.
ON
status:
Circuit between 1CN-31 and 1CN-32 is closed.
1CN-31 is at low level.
Normal state
OFF
status:
Circuit between 1CN-31 and 1CN-32 is open.
1CN-31 is at high level.
Alarm state
Alarm codes ALO1, ALO2, and ALO3 are output to indicate each alarm type.
3) Contact Output Signals ALO1, ALO2, and ALO3
Output → ALO1 1CN-37
Alarm Code Output For Speed/Torque
Control and
Position Control
Output → ALO2 1CN-38
Alarm Code Output For Speed/Torque
Control and
Position Control
Output → ALO3 1CN-39
Alarm Code Output For Speed/Torque
Control and
Position Control
Output → SG 1CN-2
Signal Ground for Alarm Code
Output
For Speed/Torque
Control and
Position Control
These signals output an alarm code to indicate the type of an alarm detected by the Ser-
vopack.
Use these signals to display alarm codes at the host controller.
3
Servopack
Alarm
detection
ALM+ output
Turns the power
OFF
To Next Page
