USING THE DIGITAL OPERATOR
4.1.6 Operation in Monitor Mode cont.
182
Monitor
#
Related I/O Signal, User
Constant
DescriptionBit #
Un-06
1 Input reference pulse
1CN-1 (PLUS), 1CN-2(£PULS)
2 Input pulse sign
1CN-3(SIGN), 1CN-4 (£SIGN)
3 Error counter clear input
1CN-5 (CLR), 1CN-6(£CLR)
4
to
12
Not used.
13 Full-closed Phase-A
4CN-2 (FA), 4CN-3 (£FA)
14 Full-closed Phase-B
4CN-4 (FB), 4CN-5 (£FB)
15 Full-closed Phase-C
4CN-6 (FC), 4CN-7 (£FC)
16
to
20
Not used.
4
